| Model | PAVA120B |
|---|---|
| Rated output power | 120W (Note: please connect high impedance speaker within this load) |
| Rated output voltage | 100V |
| Sensitivity: MIC | 5mv(±1mv) |
| Sensitivity: AUX | 1VRMS(±100mv) |
| SNR: MIC | ≥70dB |
| SNR: AUX | ≥80dB |
| Frequency response: MIC | 100Hz~10KHz(±3dB) |
| Frequency response: AUX | 80Hz~15KHz(±3dB) |
| Ratio of source emf. | ≥12dB |
| THD | ≤0.5% |
| Tone adjustment range | ±11±2 dB |
| Rated power consumption | 250W |
| AC-DC power supply switching time | No interruption |
| 12AH battery (two batteries in series into 24V) endurance | 2H (normal emergency voice broadcast) |
| Battery: Size | ≤150×100×100mm ( 2 pcs) |
| Battery: Voltage | 12V; (two in series into 24V) |
| Working Voltage | AC220V-230V/50Hz |
| Package dimensions | 570×470×271mm |
| Machine dimensions | 500×400×180mm |
| Gross weight | 17kg |
| Net Weight | 15kg(without batteries) |
Features
● 120W amplifier
● A host and backup switcher
● DC24V power charging module
● Line detection module
● Emergency broadcast microphone and a cabinet
● Remote paging
● One button alarm
● Built-in emergency voice evacuation
